Problem with downscaling 4k face to 1k

[Silver Wolf]

Hello everyone.



Recently I've come across this face texture for Fallout 4, which looks pretty interesting. The problem is it require 4k face as a base to overwrite.

(Pauline face: https://www.nexusmods.com/fallout4/mods/50650 )



I've tried to downscale it to 1k diffuse (BC1) and normal map (BC5) with 512 for specular map (BC5) using intel texture plugin for photoshop.

But it didnt work. The brown face bug is still there. Anyone can help me take a look at the mod to see if I missed something or does it require some extra step?

Or if you can please help me properly downscale it to 1k , it would be much appreciated!



Thank you



[Guest]

Try BC3 for face diffuse textures (I think it needs alpha support regardless no alpha). BC5 is for normal/spec so that should be good I think. BC1 is tint mask w/o alpha. BC3 is also for makeup with alpha.

The face I think needs different coding depending on whether it's _d, _n, _s. Switching to a 2K ruby skin setup and trying to weed out rust face myself right now, so tedious.

Edited June 27, 2021 by Guest

[JB.]

https://www.nexusmods.com/fallout4/mods/30163





Quote

• The main head diffuse texture needs to be in the BC3 (DXT5) format.
• Normal maps need to be in the BC5 (ATI2) format.
• Specular maps need to be in the BC5 (ATI2) format.



[Silver Wolf]

3 hours ago, JBpy said:

https://www.nexusmods.com/fallout4/mods/30163









Hey, this works!

Thank you
